ISUZU Refuse Compactor Truck Spare Parts List

1

Gear Pump

The gear pump is a vital component in the hydraulic system, responsible for delivering hydraulic oil to various cylinders. Due to long-term operation under high pressure and high-speed conditions, the gears and bearings inside the gear pump are prone to wear, leading to leaks or reduced efficiency. Regular inspection of the gear pump's working condition and timely replacement when abnormalities are found are key to ensuring stable operation of the hydraulic system.

2

Multi-way Valve

The multi-way valve controls the actions of multiple cylinders in the hydraulic system, with functions such as flow distribution, direction changing, and pressure regulation. The multi-way valve has high requirements for sealing and pressure resistance, and long-term use may lead to issues such as poor sealing, clogging, or leaks. Regular cleaning and inspection of the multi-way valve to ensure its normal operation are important measures for maintaining hydraulic system performance.

3

Hydraulic Hose

Hydraulic hoses are the "blood vessels" of the hydraulic system, responsible for delivering hydraulic oil to various cylinders and control valves. Due to long-term exposure to high pressure and frequent bending, hoses are prone to aging, cracking, or rupturing. Regular inspection of the hose's appearance and connections, and timely replacement when abnormalities are found, are crucial for preventing hydraulic system failures.

4

Air Pipe

Air pipes in the ISUZU rear load garbage truck are mainly used for supplying air to the pneumatic system. Due to long-term operation in harsh environments, air hoses are prone to aging, damage, or clogging. Regular inspection of the air hose's integrity and air tightness to ensure its normal operation is key to maintaining stable operation of the pneumatic system.

5

Hydraulic Cylinder

Hydraulic cylinders are the main actuating components on the ISUZU waste compactor truck, responsible for converting hydraulic energy into mechanical energy to drive the movement of components such as the pusher, loader, and tipping frame. Due to long-term operation under high pressure and high-load conditions, the seals and cylinder bodies of hydraulic cylinders are prone to wear, leading to leaks or reduced efficiency. Regular inspection of the hydraulic cylinder's working condition and timely replacement of seals or cylinder bodies when abnormalities are found are key to ensuring stable operation of the hydraulic system.

6

Cylinder Seals

Cylinder seals are a critical component of hydraulic cylinders, used to prevent hydraulic oil leaks and ingress of external impurities. Due to long-term operation under high pressure and high-friction conditions, seals are prone to wear, aging, or deformation. Regular replacement of cylinder seals to ensure their good sealing performance is key to extending the service life of hydraulic cylinders and maintaining stable operation of the hydraulic system.

7

Power Take-off (PTO)

The PTO is a device for obtaining additional power on the ISUZU waste compactor truck, usually installed on the outside of the transmission or on the clutch housing. The PTO transmits power from the transmission to components such as the hydraulic pump through gear transmission. Due to long-term operation under high-speed and high-load conditions, the gears and bearings of the PTO are prone to wear, leading to reduced transmission efficiency or failures. Regular inspection of the PTO's working condition and timely replacement of worn components when abnormalities are found are key to ensuring stable power transmission in the vehicle.

8

Manual Valve (for PTO)

The manual valve (for PTO) is a switch used to control the operation of the PTO, enabling the engagement and disengagement of the PTO through manual operation. Due to long-term frequent use, the mechanical structure inside the manual valve is prone to wear or damage. Regular inspection of the manual valve's working condition to ensure its flexibility and reliability is key to ensuring normal operation of the PTO.

9

Tailgate Seal Strip

The tailgate seal strip is used for sealing between the loader and the compartment body to prevent waste from leaking during compaction. Due to long-term exposure to pressure and friction from waste, the seal strip is prone to wear, aging, or deformation. Regular replacement of the loader seal strip to ensure its good sealing performance is key to preventing waste leakage and maintaining cleanliness of the compartment body.

10

Nylon Slider

Nylon sliders are used to reduce wear and noise between the pusher rail and the compartment track. Due to long-term exposure to pressure and friction from the push plate, nylon sliders are prone to wear. Regular inspection of the wear condition of nylon sliders and timely replacement when abnormalities are found are key to ensuring smooth movement of the pusher and extending its service life.

11

Electronic Control System Components

Electronic control system components include control boxes, photoelectric switch sensors, etc., used to control the vehicle's electrical system and monitor the vehicle's working status. Due to long-term operation in harsh environments, electronic control system components are prone to aging, malfunctions, or damage. Regular inspection of the working condition of electronic control system components and timely replacement or repair when abnormalities are found are key to ensuring stable operation of the vehicle's electrical system.

12

Solenoid Valve

The solenoid valve is a key component in the pneumatic system, used to control the on/off and direction changing of the air path. Due to long-term frequent use, the mechanical structure inside the solenoid valve is prone to wear or damage. Regular inspection of the solenoid valve's working condition to ensure its flexibility and reliability is key to ensuring stable operation of the pneumatic system.

13

Control Box

The control box is the interface for the driver to operate the ISUZU refuse compactor truck, including various buttons, switches, and indicator lights. Due to long-term frequent use, the electrical components inside the control box are prone to aging or damage. Regular inspection of the control box's working condition and timely replacement or repair when abnormalities are found are key to ensuring normal operation of the vehicle by the driver.

14

Pressure Regulating Valve

The pressure regulating valve is used to control the pressure in the hydraulic system, ensuring that each cylinder operates under the appropriate pressure. Due to long-term operation under high-pressure conditions, the mechanical structure inside the pressure regulating valve is prone to wear or damage. Regular inspection of the pressure regulating valve's working condition to ensure accurate pressure regulation is key to ensuring stable operation of the hydraulic system.

15

Air Path Filter

The air path filter is used to filter compressed air entering the pneumatic system, preventing impurities and moisture from damaging the pneumatic system. Due to long-term operation in harsh environments, the air path filter is prone to clogging or damage. Regular cleaning and replacement of the air path filter to ensure its normal operation are key to maintaining stable operation of the pneumatic system.
