15 Seats Isuzu Military passenger van

The Isuzu NKR mini bus is an outstanding model that combines practicality, performance and comfort. The Isuzu NKR model adopts a 4x2 drive configuration, left-hand drive, and is equipped with an air conditioning system to ensure a comfortable experience for the driver and passengers. The body size is 5995x2160x3240 mm, and the wheelbase is 3360 mm, which is compact yet spacious. In terms of power, it is equipped with a 2.99-liter ISUZU 4KH1CN6LB diesel engine with an output of 120 horsepower (95 kilowatts), which meets the Euro 6 emission standards, showing the perfect combination of strong performance and environmental awareness.

The transmission system adopts a 5-speed manual transmission with 1 rear speed to provide flexible control for the driver. The Isuzu mini 120HP bus can accommodate 10-14 passengers, with a curb weight of 4300 kg and a total mass of 4495 kg. The maximum speed can reach 95 km/h. Equipped with a power steering system to ensure easy control, it is equipped with a 7.00-15 specification tire to provide good driving stability.

Techincal details:

Advantage:

1. Power system: This ISUZU 4KH1CN6LB is a benchmark product of ISUZU's global technology synchronization. It is designed for high-load transportation scenarios. Users report that its climbing performance and fuel consumption performance far exceed similar models. Whether it is congested in the city or in mountainous roads, it can ensure that power is available on demand, saving fuel and worry.

—— Engine performance: ISUZU 4KH1CN6LB has a maximum power of 120 horsepower and a peak torque of 290N·m. The low-speed torque adjustment is optimized to adapt to frequent start-stop and ramp conditions in the city, and the power response is fast.

—— Environmental compliance: It adopts Denso high-pressure common rail technology (injection pressure 1800bar), with excellent atomization effect, improved combustion efficiency, taking into account both power and economy, and fuel consumption rate is 10% lower than the same level of competitors.

—— Transmission matching: It is equipped with Isuzu MSB 5-speed manual transmission, with high transmission efficiency and smooth gear shifting. The reliability has been verified by 600,000 kilometers without major repairs, and the maintenance cycle is long, which reduces the user's life cycle cost.

2.Chassis and body design: The Isuzu NKR mini bus perfectly combines Isuzu's chassis genes with localization needs. It can easily cope with urban height-restricted areas and meet the complex road conditions in towns and villages.

——Chassis advantages: Developed based on the original Isuzu light-duty NKR model, it has a wheelbase of 3360mm, a small turning radius (optimized to 2.8 meters), strong passability, and is suitable for narrow streets and rural roads.

——Lightweight and load-bearing: The frame uses high-strength steel and aluminum alloy components, and its deadweight is reduced by 228.6kg. At the same time, through 28 structural optimizations, the load-bearing capacity is increased by 47%, the curb weight is 4300kg, and the total mass is 4495kg, which is light and flexible.

——Space layout: The body size is 5995×2160×3240mm, and the compact design realizes a flexible layout of 10-14 seats, with strong adaptability to cargo and passenger scenarios, and the utilization rate of cargo compartment or seat modification space is more than 75%.

3. Comfort and safety: CEEC Trucks has optimized NVH performance and seat ergonomics specifically for passenger transport scenarios, and passengers reported that the riding experience is close to that of passenger cars. In terms of safety, Isuzu's original chassis and braking system have been verified for millions of kilometers, and the failure rate is only 1/3 of the industry average, allowing you to rest assured every trip.

—— Driving comfort: standard air conditioning system and adjustable seats, cab noise optimized to the industry-leading level, long-term driving fatigue significantly reduced; steering wheel power steering system and wide-range rearview mirror design, light operation and wide field of vision.

—— Safety configuration: equipped with ABS anti-lock braking system and brake booster pump, the brake response is sensitive, and the braking distance is shortened under full load conditions; tire specifications are 7.00-15, with strong grip and excellent high-speed driving stability.
