Isuzu 8cbm lubricant oil supply fuel lube service truck
Isuzu 8cbm lubricant oil supply fuel lube service truck also called Isuzu 8 cbm fuel lubrication service truck,Isuzu lubricant oil supply service truck,Isuzu fuel Lube service truck,Isuzu 240HP fuel and lubrication service trucks on sale,Isuzu Lube maitenance lubrication oil service truck.The Isuzu 8cbm lubricant oil supply fuel lube service truck is a versatile, reliable workhorse designed to meet a variety of needs in the automotive, construction, mining and industrial sectors. This dedicated vehicle combines the durability and performance of Isuzu's renowned engineering with a custom configuration optimized specifically for fuel and lubrication services. With its rugged structure, efficient fuel delivery system and comprehensive lubrication capabilities, the Isuzu 8 CBM fuel lubrication service truck is a valuable asset to any fleet or maintenance operation.
The Isuzu 8 cbm fuel lubrication service truck is a service truck that combines advanced technology with rugged construction. The steel-constructed chassis ensures stability and houses advanced fuel and lubrication systems. Its 8 cubic meter fuel storage capacity ensures continuous operation, while the precision-engineered lubrication system helps maintain equipment performance. Equipped with a real-time monitoring system and a user-friendly control panel, it provides the critical data and operational convenience that operators need. This truck is highly adaptable to different industries and environments, while its strict environmental and safety standards reflect its commitment to sustainability and operator safety. With a comprehensive support framework including maintenance services and technical support, the Isuzu 8 cbm Fuel Lubrication Service Truck demonstrates its excellence and commitment to service.
Isuzu 8 cbm fuel lubrication service truck
Chassis
Brand
Isuzu
GVW(kg)
16000
Curb weight(kg)
9000
Wheelbase(mm)
4500 mm
Dimensions(mm)
8400X2460X3100 mm
Front/Rear Axle loading(kg)
6000/10000 kg
Wheel track (front/rear) (mm)
1880/1800 mm
Front/Rear overhang(mm)
1430/2470 mm
Max. driving speed(km/h)
105 km/h
Clutch
Reinforced diaphragm clutch
Brakes
Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheelsAuxiliary brake: engine exhaust valve brake
Steering Gear
Power steering, hydraulic steering with power assistance
Tire
Quantity
6 pcs with one spare tire
Specifications
295/80R22.5
Transmission
Manual type, FAST 8-speed
Cab
It can accommodate three people. With Air Conditioner
Engine
Brand
Isuzu
Model
6HK1-TCG61
Fuel type
Diesel
Displacement(ml)
7790 ml
Power(kw)
177kw
Horsepower(HP)
240HP
Cylinder type
Inline 6 cylinder
Emission standard
Euro VI
Fuel Tank
Fuel tank
Capacity(cbm)
8cbm
Tank material
Tank material:Q235 high tensile strength steel.
Thickness(mm)
Side 5 Bottom 6
Baffle
1 No,4 mm carbon steel
Manhole cover
1 manhole cover, ∮500mm 1 set with breather valve
Bottom Valve
1 set of API Pneumatic Bottom Valve
Discharging valve
1 set ∮ discharging valve
Handrail
Two sides
Ladder
At rear of tank
Painting
Color and design as customer's requirement
The Isuzu 8 cbm fuel lubrication service truck is a strong asset in the service vehicle segment, meticulously built to provide comprehensive fuel and lubrication solutions for a wide range of industries. Combining rugged construction with advanced technology, this versatile truck is designed to improve operational efficiency, minimize downtime and ensure optimal performance in different working environments.
Isuzu 8 cbm fuel lubrication service truck
Design and Construction:
At the heart of this truck is a rugged chassis made from high-strength steel to ensure stability and longevity even in demanding conditions. The body has also been designed with functionality and durability in mind, with reinforced panels and corrosion-resistant materials to withstand the rigors of daily use and harsh environments. The truck’s aerodynamic design not only enhances its visual appeal, but also helps improve fuel efficiency, thereby reducing operating costs.
Engine and Powertrain:
Powering this powerful machine is an Isuzu diesel engine, which is renowned for its reliability, fuel efficiency and low maintenance requirements. Paired with a smooth-shifting transmission system, the engine ensures seamless power delivery, allowing the truck to traverse a variety of terrains with ease. The engine's powerful torque output ensures the truck can handle heavy loads with ease, making it ideal for transporting large quantities of fuel and lubricants to remote job sites.
Isuzu lubricant oil supply service truck
Fuel Delivery System:
The Isuzu lubricant oil supply service truck features an advanced fuel delivery system designed for efficiency and safety. The truck is equipped with multiple fuel tanks, each with a large capacity, allowing for extended operating range without frequent refueling. The tanks are made of durable materials and feature an advanced leak detection system to minimize the risk of environmental contamination.
The fuel delivery system uses a high-pressure pump and precision metering device to ensure accurate and efficient fuel dispensing. This allows technicians to quickly and accurately refill vehicles or equipment with the required amount of fuel, minimizing waste and maximizing productivity. In addition, the system is designed to be compatible with a variety of fuel types, including diesel, gasoline and even specialty lubricants, making the truck a versatile solution for a variety of applications.
Lubrication Capabilities:
In addition to its fuel delivery capabilities, the Isuzu 8 CBM Fuel Lubrication Service Truck also excels in lubrication services. The truck is equipped with a comprehensive lubrication system, including a range of pumps, hoses and dispensing devices designed to apply various types of lubricants. The system enables technicians to quickly and easily lubricate moving parts, bearings and other components, reducing friction, wear and the risk of failure.
The lubrication system is designed to be user-friendly, with intuitive controls and clear labeling, making it easy for technicians to select the correct lubricant and apply it accurately. The system also incorporates safety features such as a pressure relief valve and an automatic shut-off mechanism to minimize the risk of accidents or leaks.
Isuzu 8cbm lubricant oil supply fuel lube service truck
Storage and Organization:
The Isuzu fuel Lube service truck is designed with ample storage space to accommodate all the necessary tools, equipment and supplies required for fuel and lubrication services. The truck’s interior layout is well thought out, with custom-designed compartments and drawers that provide easy access to everything from wrenches and sockets to spare parts and safety gear.
The truck also features a spacious and comfortable cab designed to keep the driver comfortable and focused on the task at hand. The cab is equipped with modern amenities such as air conditioning, power steering and a comfortable driver’s seat, ensuring that the driver can stay alert and productive even during long shifts.
Versatility and Customization:
One of the main advantages of the Isuzu 8cbm lubricant oil supply fuel lube service truck is its versatility and customizability. The truck can be configured to meet the specific needs of different industries and applications, with options such as additional fuel tanks, dedicated lubrication systems and custom storage solutions. This enables customers to tailor the truck to their exact needs, ensuring it is a perfect fit for their unique operation.
Environmental Responsibility and Safety Protocols
Isuzu Service Trucks is firmly committed to environmental sustainability and operational safety. Emission control mechanisms and efficient fuel combustion systems are carefully designed to meet strict environmental standards, reducing the truck's carbon footprint and promoting environmentally friendly practices. Strict safety protocols, including powerful braking systems and fire extinguishing mechanisms, as well as a comprehensive operator training program, emphasize the truck's commitment to prioritizing personnel safety and ensuring compliance with regulatory guidelines.
Isuzu 240HP fuel and lubrication service trucks on sale
Isuzu 8 cbm fuel lubrication service truck is a multi-functional service vehicle designed for on-site fuel supply, lubrication service and emergency repair. It has high flexibility, efficiency and versatility, and is suitable for various industrial occasions that require on-site services. Its use mainly revolves around the provision of fuel and lubrication services, especially for occasions that require on-site refueling, lubrication and maintenance. The following is a detailed description of the vehicle's use:
Ⅰ. Main uses
●. Fuel supply:
★. The vehicle is equipped with an 8 cubic meter fuel storage tank, which can store and transport fuel (such as diesel, gasoline, etc.) to provide on-site refueling services for various equipment, vehicles or machinery.
★. It is suitable for places such as construction sites, mines, oil fields, ports, etc. that are far away from fixed gas stations, and occasions where frequent mobile refueling is required.
Isuzu Lube maitenance lubrication oil service truck
●. Lubrication service:
★. The vehicle may also be equipped with a lubrication system, such as a lubricating grease pump, a grease dispenser, etc., to provide on-site lubrication services for various mechanical equipment.
★. This helps reduce equipment wear, improve operating efficiency and extend service life.
●. Mobile maintenance:
★. As a service vehicle, it can also carry necessary maintenance tools and spare parts to provide emergency maintenance services for on-site equipment.
★. When equipment fails, it can respond quickly and solve the problem to reduce downtime.
Fuel tank
Ⅱ. Applicable scenarios
★. Construction site: Provide fuel and lubrication services for construction machinery (such as excavators, loaders, rollers, etc.).
★. Mining operations: Provide on-site refueling and lubrication services for mining equipment (such as mine cars, excavators, crushers, etc.).
★. Oilfield development: Provide fuel and necessary maintenance services for drilling equipment, oil production equipment, etc.
★. Port logistics: Provide fuel supply and lubrication maintenance for port machinery and equipment (such as cranes, forklifts, transport vehicles, etc.).
Ⅲ. Features and advantages
★. High flexibility: It can be flexibly moved to various places where services are needed, without being restricted by fixed gas stations or maintenance stations.
★. High efficiency: Provide fuel and lubrication services on-site to reduce the downtime of equipment due to lack of oil or wear.
★. Versatility: Not only provides fuel services, but also can perform lubrication and simple maintenance to meet a variety of on-site needs.
★. Economical: Reduce the cost and time consumption caused by transporting fuel or equipment over long distances to fixed service stations.
Ladder and guardrail
Dynamotor
Lubricating oil reel
