Isuzu new 100P broom sweeper truck
Isuzu new 100P broom sweeper truck also called Isuzu brush type street sweeping truck,Isuzu 100P road sweeper truck,Isuzu ELF 5.5 cbm street sweeper truck,Isuzu NPR 100P vacuum sweeper with brush.The Isuzu new 100P broom sweeper truck is a professional cleaning equipment that combines efficiency, durability, and environmental friendliness. It is designed specifically for urban road cleaning and has won widespread praise in the market for its excellent performance and user-friendly design.
The Isuzu 100P road sweeper truck stands as a beacon of efficiency and innovation in the realm of urban cleanliness. This road sweeper truck integrates cutting-edge technology with robust design elements to ensure cities remain pristine, streets free of debris. At its core lies a powerful engine that effortlessly propels the vehicle forward, addressing sweeping needs with unparalleled precision and speed.
Specifications
Isuzu new 100P broom sweeper truck
Main Specification
Vehicle Brand
Powerstar
Chassis Brand
ISUZU NEW ELF 100P
Overall dimensions (L x W x H)
5860x2300x2450 mm
Drive Type
4x2 Left hand drive
Wheelbase
3360mm
Cabin
Isuzu N-series cab, with A/C and 2 seats, Forward control, all steel welded construction. Manual tilt,Mechanical suspension
Weight
GVW
7300kg
Kerb weight
5040kg
Engine
Model
Isuzu 4KB1-TCG60
Type
Inline 4-cylinder diesel engine
Power
130HP/96Kw
Displacement
2499ml
Emission standard
Euro 6
Transmission
Manual
ISUZU MSB 5 forward and 1 reverse speeds
Tyre
7.00R16
6+1 spare tyre
Upper Structure Parameter
Volume of water tank
1500L
Volume of Dustbin
4000L
Material
water tank
Carbon steel
garbage tank
Inner stainless steel, outer carbon steel
Hydraulic valve
Taiwan famous brand
Hydraulic motor
Domestic famous brand
Switch
Schneider control switch
Auxiliary Motor
Brand
ISUZU 493
Horsepower
77HP
Sweeping Technical
Max sweeping width (mm)
3.5m
Max. sweeping capacity
70000m3/h
Sweeping speed
3-20km/h
Cleaning efficiency
≥95%
Max. particle inhalation
110mm
Disc plate brush extension size
>400mm
Garbage tank door max.discharge angle
>50°
Sweeping system
Type
Total 4 pcs mechanical brushes and 1 sucking discmounted in the rear, it is driven by the hyraulic motoispeed is adjustable, can be independently controlled,has automatic avoidance function
Sweeping brush diameter
ф 850mm
Sweeping disk speed
1 10r/min high-speed,80r/min medium speed50r/min low-speed
Sweeping disk dip angle adjust
forward 4 ° ~ 6 ° extroversion 4 °~ 7 °
Sucking disc
Type
Double suction hole, hydraulic control, spring suspension
Suction hole diameter
180mm
Suction performance
Delivers air blast and suction
Hydraulic system
Type
Open type, electrical
Main components
Gear pump, hydraulic motor, hydraulic cylinder, solenoid valve
Pressure
16Mpa
Hydraulic oil volume
60L
Oil temperature
60°C
Water spraying system
Components
Pump, nozzle, water filter, etc.
Low pressure water system
Model
Hangzhou Weilong 60/90
Flow rate
60m3/h
Water delivery distance
90m
Washing width
24m
Washing road
Type
Front washing bar
Electrical system
Type
DC24V, PLC control
Volts
24V
Battery
2x12V
Tools
2 pcs fire hose,1 pcs fire wrench,1pcs water filter wrench,1 set chassis tools,1 pcs manual hydraulic pump rocker
Spare parts
88 pcs sweep brush,1 pcs fan seal,1 pcs rear door seal,2 pcs suction tube seal
Applications
Isuzu new 100P broom sweeper truck is a professional road cleaning equipment that integrates efficient cleaning, stable performance, environmental protection and energy saving, and intelligent operation. The vehicle is equipped with a powerful cleaning system and a maintenance-free centrifugal fan to ensure large-area, high-efficiency cleaning operations; it adopts advanced power systems and stable control technology to provide long-lasting and reliable power support and a comfortable driving experience; at the same time, it focuses on environmentally friendly design, reduces emissions and promotes classified resource utilization. The intelligent operation interface and remote monitoring system make operation easier and maintenance more convenient. It is suitable for a variety of scenarios such as urban roads, highways, public places and industrial parks, and is an ideal choice for urban cleaning operations.
Isuzu new 100P broom sweeper truck
ISUZU 5.5cbm road sweeper truck drawing
★ Power system
Isuzu Brush type Street sweeping Tuck is modified on the basis of Isuzu's new 100P chassis. The chassis is equipped with an advanced Isuzu 4KB1-TCG60 130HP diesel engine, which is more powerful, fuel-efficient and low-emission compared to the previous 120HP engine. The engine has been carefully tuned and optimized to ensure the stability and reliability of the vehicle under various working conditions. At the same time, the vehicle is also equipped with an intelligent transmission system and an advanced suspension system to further improve the stability and comfort of driving.
Isuzu 77HP auxiliary engine
Isuzu 77HP auxiliary engine is an important power component on the Isuzu road sweeper, designed for auxiliary sweeping operations. This auxiliary engine originated from Isuzu Motors and is known for its high efficiency, reliability and energy saving. The output power of 77 horsepower ensures that key components such as the sweeping system, sprinkler system and dust collection device can operate stably and efficiently.
Isuzu Brush type Street sweeping Truck
The Isuzu 77HP auxiliary engine uses advanced fuel injection technology and an optimized combustion chamber design to improve fuel economy and reduce emissions. At the same time, the engine is also equipped with an intelligent control system that can automatically adjust the power output according to the needs of the sweeping operation to achieve the best balance between energy consumption and efficiency.
In terms of maintenance, the Isuzu 77HP auxiliary engine adopts a modular design that is easy to disassemble and inspect, making repair and maintenance work more convenient. In addition, the engine is also equipped with a complete protection system, including overheating protection, oil pressure protection, etc., to ensure the safe operation of the engine under various harsh working conditions.
Isuzu ELF 5.5 cbm street sweeper truck
★ Water tank and garbage bin
The Isuzu new 100P road sweeper is equipped with a spacious 1.5 cubic meter carbon steel water tank to ensure continuous water supply to suppress dust during sweeping operations. This large capacity can extend the operating time without frequent water additions, thereby optimizing productivity. Complementing this, it is also equipped with four square stainless steel garbage bins, each of which can accommodate a large amount of garbage. This setup enhances the truck's waste management capabilities and promotes a thorough and comprehensive cleaning process.
● 1.5 cubic carbon steel water tank:
·Material: The water tank is made of high-quality carbon steel material, which has the characteristics of high strength, corrosion resistance and long service life.
·Capacity: The 1.5 cubic meter capacity design ensures that the sweeper has sufficient water source when cleaning the road.
·Design: The inside of the water tank has been specially treated and is not easy to rust and scale.
·Function: The water tank is closely connected with the cleaning system. The water is sprayed on the ground by a high-pressure water pump, and the cleaning brush is used for cleaning to effectively remove stains and dust on the road.
Isuzu 100P broom sweeper truck
● 4 cubic stainless steel dusbin:
·Material: The inner layer of the dustbin is made of stainless steel and the outer layer of carbon steel. It has excellent corrosion resistance and wear resistance, and can keep clean and hygienic for a long time.
·Capacity: The 4 cubic meter capacity design can meet the needs of long-term cleaning operations and reduce the number of frequent dumping of garbage.
·Design: The inside of the dustbin is smooth and flat, and it is not easy to leave garbage and dirt. At the same time, it is equipped with a garbage compacting device to improve the efficiency of garbage collection.
·Function: The garbage bin is connected to the cleaning system, and the garbage and dust on the ground are sucked into the garbage bin through negative pressure suction, realizing the simultaneous cleaning and collection.
Isuzu NPR 100P vacuum sweeper with brush
★ Cleaning system
The cleaning system is the core part of the vehicle, mainly composed of cleaning brushes, high-pressure water pumps, negative pressure dust suction devices, etc. The arrangement of four central sweeping brushes and rear suction ports is adopted, which makes the cleaning width large and the efficiency high.
The cleaning brush is made of wear-resistant material and can effectively remove stains and dust on the road;
The high-pressure water pump provides strong water pressure to spray the cleaning water onto the ground;
The sturdy brushes installed in strategic locations can effectively collect dust and larger objects to keep the road clean. Its cleaning width covers a considerable area, minimizing the operation time while maximizing the cleaning efficiency.
The negative pressure dust suction device sucks the garbage and dust on the ground into the garbage bin through strong suction. The entire cleaning system works together to achieve efficient and fast cleaning results.
Isuzu NPR 100P street washing and sweeping truck
★ Weiye 6.0 maintenance-free centrifugal fan
The Weiye 6.0 maintenance-free centrifugal fan is a key dust suction component on the Isuzu ELF 100P road sweeper. This fan is popular for its high efficiency, low noise and maintenance-free features. The 6.0 model represents its powerful suction capacity and efficient air handling capacity.
The Weiye 6.0 maintenance-free centrifugal fan adopts an advanced centrifugal design, which can generate high negative pressure at low speed and effectively absorb garbage and dust on the ground. At the same time, the fan is also equipped with an efficient filtration system that can filter out fine particles in the air to ensure that the discharged air meets environmental protection standards.
The maintenance-free design makes this fan unnecessary to frequently replace the filter or perform other maintenance work during use, greatly reducing the cost of use. In addition, the fan also uses low-noise technology to ensure quietness and comfort during the cleaning operation.
★ Control system
Isuzu100P 5.5 cubic meter road sweeper is equipped with an advanced control system, including various instruments and buttons in the cab, the road sweeper work operation box and the box operation control box under the tail of the box. The driver can easily control the vehicle's driving, sweeping, watering, vacuuming and other actions through the control system.
Isuzu light vacuum street diesel sweeper truck
★ Hyderava solenoid valve group
Hyderava solenoid valve group is one of the important control systems on this road sweeper. This solenoid valve group is known for its high precision, high reliability and long life. It is responsible for controlling the switching and adjustment of key components such as the watering system, vacuuming system and garbage compaction device on the sweeper.
Hyderava solenoid valve group adopts advanced solenoid valve technology, which has the characteristics of fast response, precise control and stable and reliable. By precisely controlling the switching and adjustment of each component, the solenoid valve group can ensure that the sweeper can maintain the best working condition under various working conditions.
At the same time, the solenoid valve group is also equipped with a complete protection system, including overload protection, short circuit protection, etc., to ensure the safe operation of the solenoid valve during long-term use. In addition, the solenoid valve group is designed to be easy to disassemble and inspect, making repair and maintenance more convenient.
Cab operation box
Isuzu's new 100P road sweeper truck is widely used in the following scenarios with its excellent performance and efficient cleaning ability:
Urban roads: suitable for daily cleaning operations on urban roads to keep the roads clean and beautiful.
Highways: suitable for regular cleaning operations on highways to improve road cleanliness and driving safety.
Public places: suitable for cleaning operations in public places such as squares, parks, schools, hospitals, etc. to ensure a clean environment and public health.
Industrial parks: suitable for cleaning operations in industrial parks and factory areas to keep the production environment clean and safe.
Other places: cleaning operations at transportation hubs such as stations, docks, and airports to improve service quality.
Isuzu Auxiliary engine
Weiye Fan
Lifting cylinder
Sweep brush
Sucker
Rear operation box
